Advanced PEM Technology
PEM Electrolyzers
PEM Electrolyzers
Green Soluation’s proton-exchange membrane (PEM) technology delivers high efficiency, rapid response times, elevated output pressure, and low power consumption. We provide customized solutions to meet customer needs, including scalable plant designs and containerized systems.
Dew Point
-70˚C
Stack Size
Up to 1.5 MW
Operating Range
5% - 110%
Product Advantages
The Power of Green Soluation’s PEM Electrolyzers
Fast Response Times
Adapts in under 3 seconds, ensuring seamless operational flexibility.
01
High Efficiency
Optimized with a 4.3 kWh/Nm³ standard DC power consumption, with customizable options for maximum efficiency.
02
Proven & Scalable
Successfully deployed in commercial projects exceeding 1 MW, demonstrating reliability and scalability.
03
Compact Configurations
Containerized solutions designed for durability, efficiency, and space optimization.
04
Wide Operating Range
Handles fluctuations effortlessly, operating between 5% and 110% load capacity.
05
Safe Operation
Equipped with remote monitoring, automated safety features, and fault diagnostics for maximum reliability.
06
Maximizing Efficiency
Key Parameters
| HGPS 50 | HGPS 300 | ||
|---|---|---|---|
| Hydrogen Generation | 50 Nm³/h | 300 Nm³/h | |
| DC Power Consumption | 4.3 kWh/Nm³ | ||
| System Efficiency | 80% | ||
| Output Pressure | 3.0 MPa | ||
| Operation Range | 5% - 110% | ||
| Hydrogen Purity | 99.999% | ||
| Dew Point Temperature | ≤ -70°C | ||
| Dl Water Consumption | 50 L/h | 300 L/h | |
| Operation Temperature | 65°C | ||
| Start-up Time | 30 sec (warm start)/5min (cold start) | ||
| Service Life | 70,000 h |
